Dal som ho zmontovať v profesionálnom servise, prešiel testovacími jazdami na vychytanie múch a opravenie chybičiek z výroby. Dal som tam bmx pedále Longus s pinmi pre lepšiu stabilitu. Je na ňom záruka 2 roky.
Keďže tento typ biku si pýta pravidelný servis, viem odporučiť servis, ktorý má k dispozícii software na prehliadku, diagnostiku a update firmwaru a vie opraviť bike aby sa na ňom dalo jazdiť bez problémov.
hmotnosť
21,9 Kg
rám
Prime Xtralite 6061 Full Butted Alloy, Forward Geometry, intenal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor
vidlica
RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
hlavové zloženie
Onoff Saturn tapered for 1-1/8 to 1-1/2 head tube, ACB sealed bearings, top 41×30.2x7x45x45, bottom 51.9x40x8x45x45
prehadzovačka
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
radenie
Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click
brzdové páčky
Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
kľuky
Race Face Aeffect ebike, 165mm
riadidlá
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9 backsweep, 5 upsweep, 31.8mm barbore Onoff Twin, 1lock-on, 135mm
predstavec
Onoff Sulfur FG 30mm 0, 6061 forged alloy, 31.8mm barbore
sedlovka
Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
sedlo
Mondraker e-MTB custom design
náboj predný
Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts
náboj zadný
Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts
reťaz
Sram SX Eagle, 12s, Powerlock
kazeta
Sram PG-1210, 11-50T, 12s
drôty
CN round stainless steel
ráfiky
MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes
plášte
Maxxis Rekon 29×2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
predná brzda
Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad
zadná brzda
Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
plášť zadný
Maxxis Rekon 29×2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
prevodník
Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
pätka k prehadzovačke
Mondraker M068
motor + batéria
Bosch Performance Line CX Cruise (25Km/h) GEN4, computer Bosch Purion, Bosch Powertube 625Wh
